Sinusoidal Metal Corrugated Sheet Making Machine 380V Customized

Ulasan pelanggan
Mesin mudah digunakan. Bosnya sangat baik.

—— Mr.Angolon Dari Eropa

Ini adalah produsen yang bagus, komunikator bahasa Inggris yang baik, dan saya suka mesin Anda. Kualitasnya bagus, dan cantik!

—— Mr.Mark Dari Afrika

Pemasok yang bagus! Saya suka pengiriman cepat dan siklus produksi cepat, akan tetap berhubungan dengan kalian.

—— Mr.Jack Dari Amerika

I 'm Online Chat Now

Sinusoidal Metal Corrugated Sheet Making Machine 380V Customized

Sinusoidal Metal Corrugated Sheet Making Machine 380V Customized
Sinusoidal Metal Corrugated Sheet Making Machine 380V Customized
Sinusoidal Metal Corrugated Sheet Making Machine 380V Customized Sinusoidal Metal Corrugated Sheet Making Machine 380V Customized Sinusoidal Metal Corrugated Sheet Making Machine 380V Customized Sinusoidal Metal Corrugated Sheet Making Machine 380V Customized Sinusoidal Metal Corrugated Sheet Making Machine 380V Customized Sinusoidal Metal Corrugated Sheet Making Machine 380V Customized

Gambar besar :  Sinusoidal Metal Corrugated Sheet Making Machine 380V Customized

Detail produk:
Tempat asal: CN
Nama merek: HC
Sertifikasi: ISO CE
Nomor model: HC25205-1025
Syarat-syarat pembayaran & pengiriman:
Kuantitas min Order: 1 set
Harga: USD10000-16000 per set
Kemasan rincian: Standard Export Package
Waktu pengiriman: 40 days
Syarat-syarat pembayaran: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Menyediakan kemampuan: 20 set per month

Sinusoidal Metal Corrugated Sheet Making Machine 380V Customized

Deskripsi
Type: Corrugated Sheet Making Machine Suitable market: Asia
Usage: Roof and wall Power: 4+4KW
Voltage: 380V or customized Worker: 1 only
Forming speed: 10-20m/min Life time: 20 years above
Warranty: Whole life
Cahaya Tinggi:

roof tile roll forming machine

,

cold roll forming machine

Corrugated Sheet Making Machine



We are one of the leading organization occupied in providing Metal Roofing Sheet Roll Forming Machine, which are producing by using high grade material.we designed a lots kinds of Metal Roofing Sheet Roll Forming Machine. due to the high graded superiority and our client fulfillment,The product by Metal Roofing Sheet Roll Forming Machine has many benefit such as beautiful and colorful outside, light weigh, long life durability. It was widely used in every corn world wide. we can develop special Metal Roofing Sheet Roll Forming Machine as per customer requirement.



Quick Details Corrugated Sheet Making Machine

1. Suitable to process: Color steel plate
2. Width of the plate: 1200mm
3.  Rollers: 11 rows
4. Dimensions: 5.8*1.55*1.51m
5. Power: 4+4kw
6. Rolling material: high grade 45# steel(plated chrome on surface)
7. Thickness of the plate:0.3-0.6mm
8. Voltage: 380V 50Hz 3phases
9. Material of the cutting plate: Cr12

10. Hydraulic: 40#
11. Processing precision: Within 1.00mm
12. Control system: PLC control
Please note: All the parameters can be designed as customer's requirements.



Clear about working process for Corrugated Sheet Making Machine?
Decoiling--Feeding & Guiding--Roll Forming--Cutting--Finished Products To Support Table

No.

   Main parameter of Corrugated Sheet Making Machine

1

Suitable to process

Color steel plate

2

Width of the plate

1200mm

3

Rollers

11 rows

4

Dimensions

5800*1550*1510mm

5

Power

4+4kw

6

Rolling material

45# steel(plated chrome on surface)

6

Thickness of the plate

0.3-0.6mm

7

Productivity

8-10m/min

8

Diameter of the roller

Φ70mm

9

Voltage

380V 50Hz 3phases

10

Material of the cutting plate

Cr12

11

Hydraulic

40#

12

Processing precision

Within 1.00mm

13

Control system

PLC control

Why choose Huachen ?


1. Q: Do you have after sales support?
A: Yes, we are happy to give advice on machine operating and maintenance. we also have skilled technicians available abroad to help you.We need your machines running in order to keep your business running.

2. Q: How do your machines compare with other big companies in this market?
A: We are up to date with the latest technology and improve our machines accordingly .We need to make gress to move forward.

3. Q: How does your factory do regarding quality control?
A: Quality is priority.To all Huachen people,the concept "Control every process and perfect all products" is curved in mind. Every product will be fully assembled and carefully tested before it's packed for shipment.

4. Q: Do you sell only standard machines?
A: No, most of our machines are designed according to customers specifications,we offer OEM service.

5. Q: Will you deliver the right goods as ordered? How can I trust you?
A: Yes, we will. welcome to come and check your machine after finished, or we will show you machine working video for confirm. Then delivery.
