Detail produk:
|
| Material: | PPGi GI | capacity: | 20m/min |
|---|---|---|---|
| machine weight: | 4.5T | rollers: | 45# steel |
| Type: | Roof Sheet Roll Forming Equipment | cutting blade: | Cr12 |
| Cahaya Tinggi: | roof tile roll forming machine,roof panel roll forming machine |
||
Parameter for reference
| Description | Specification | |
| Main moter power | 5.5KW | |
| Hydraulic station power | 4KW | |
| Hydraulic oil pump | CB-E310 | |
| Sprocket | P-25.4 | |
| Roller station | 14 | |
| Yield strength | 32MPa | |
| Diameter of principal axis | 95MM | |
| Material of roller | 45#steel hard chrome plating | |
| Processing speed | 8m/min | |
| Thickness | 0.3-1mm | |
| Installation dimension about(L*W*H) | 7.5*1.5*1.2M | |
| Total weight | 3.8T | |
| Equipment parts includes:forming machine,hydraulic cutter,hydraulic station,electric controlling system,counter,product supporter | ||
Material of main equipment of Roll Forming Machine
1 Roller material: high grade No.45 forged steel, plated hard chrome on the surface of roller with thickness 0.05mm
2 Active shaft material: high grade No.45 carbon wrought steel at diameter 75mm
3 Cutter blade: Cr12 mould steel with quenched treatment
4 Eletric elements: control systerm with PLC model S7-200,Siemens transducer with ABB control panel with TP 170, Siemens it can input 10 sets of spec at one time
5 Oil tank model of hydraulic systerm: CB-E310
(They can be modified according to customer requirements)
Usage:
Color steel roll forming machine is widely used in producing color steel sheet for buildings.
