Galvanized Roofing Sheet Roll Forming Machine , Durable Roll Forming Equipment

Galvanized Roofing Sheet Roll Forming Machine , Durable Roll Forming Equipment
Galvanized Roofing Sheet Roll Forming Machine , Durable Roll Forming Equipment
Galvanized Roofing Sheet Roll Forming Machine , Durable Roll Forming Equipment Galvanized Roofing Sheet Roll Forming Machine , Durable Roll Forming Equipment

Gambar besar :  Galvanized Roofing Sheet Roll Forming Machine , Durable Roll Forming Equipment

Detail produk:
Place of Origin: Botou Hebei China
Nama merek: HC
Sertifikasi: ISO
Model Number: HC25
Syarat-syarat pembayaran & pengiriman:
Minimum Order Quantity: 1set
Harga: 8000-29000USD
Packaging Details: Main machine is nude,the computer control box is packed by carton box
Delivery Time: 30days
Payment Terms: 30% deposit by T/T in advance and 70% balance after inspection confirmation before shipment
Supply Ability: 20 sets/month
Kontak

Galvanized Roofing Sheet Roll Forming Machine , Durable Roll Forming Equipment

Deskripsi
type: High Strength and 1220,1250mm Feeding Width Glazed Tile Roll Forming Machine with 8 - 20m/min Working Speed for Roof Applications Roof panel are high strength and durableare with smooth beautiful appearance,uniform lacquer weins,so widely used in rollers: 19
roller material: No.45 steel warranty: 12 month
Weight: 3.2T Sertifikasi: CE/ISO9001
Roller material: 45# Steel, Hard Cr Plated
Cahaya Tinggi:

roof tile roll forming machine

,

roof panel roll forming machine

Galvanized Roofing Sheet Roll Forming Machine , Durable Roll Forming Equipment







Applications



Roof panel are high strength and durableare with smooth beautiful appearance,uniform lacquer weins,so widely used in building: the steel-structured large-scale warehouses, stadiums,shopping malls, trade markets, holiday villages, sanatoriums, hotels, villas, residences, and different kinds of greenhouses. What's more, equipment can be designed and manufactured as customers' requests.So they are popular with customers at home and aborad,especially in the Middle East,African countries,Russis,the annual demand has a rising trend.







Technics flow



Decoiling → Feeding the steel sheet → Guiding → Roll forming → Cut to length → products stacking → move out products lengthwayst







Technical Speciations



Item Parameter Remark
Material Type Galvanized sheet, As customer’s requirements
Thckness (mm) 0.4-0.8
Width (mm) 1220/1250mm Depend on different profiles
Producing speed (m/min) 8 - 20m/min Select the final design according to customer’s needs of production capacity and requirements
Forming Stations 18 - 26 Depend on Profiles
Total power (kw) 15 Depend on different technical requirements
Voltage 380V,50HZ,3Phase can be changed as customer's requirements
Roller material 45#steel quenched treatment with mirror polishing
Shaft material 40Cr temper treatment
Shaft diameter 75mm
Cutter material Cr12Mov quenched treatmentHRC48 - 52°
Control system PLC panasonic
Measure tolerance 10m±1.5mm







Main technical features

  1. Adopt independence guide post supporting wall plate and inside transmission chain, the rollers are treated with mirror polishing.
  2. Setup the sheet pre-cutting equipment to avoid waste of raw material.
  3. Procedure control and encoder measuring the length.
  4. Adopt procedure control stacher which will automatically stack, take count and move out the procducts.

Galvanized Roofing Sheet Roll Forming Machine , Durable Roll Forming Equipment 0

Galvanized Roofing Sheet Roll Forming Machine , Durable Roll Forming Equipment 1

Label:

roof tile roll forming machine,

roof panel roll forming machine,

cold roll forming machine
