| type: | Electric Control Standing Seam Metal Roof Machine | rollers: | 19 |
|---|---|---|---|
| roller material: | No.45 steel | warranty: | 12 month |
Introduction
This cameroon aluminium zinc roof sheets roll forming machine adopts Mitsubishi PLC control system, so the operator can set parameters like sheet quantity, sheet length into the touching screen, then this machine will produce corrugated galvalume roof sheets automatically. The corrugated zinc steel roofing sheets manufactured by this roll forming machine is to give a strong and reliable ability that can perform in serious outdoor conditions. With a different thickness, these sheets are best suited for domestic roofing and walling, and are available in a range of lengths to suit roofer's needs. The versatile corrugated profile can reflect both modern and traditional architecture depending on the application.
● Corrugated profile
● Suitable for roofing and walling
● 762mm coverage width after overlap
● High quality Steel construction
● Available in a range of lengths
Technical Specifications Cameroun Alu-zinc Roof Sheet Corrugating Machine
| Technical Items | Details | |
| Raw Material | Type | Aluminium & Steel Coils, PPGI, GI, PPGL |
| Width | 1200 mm | |
| Thickness | 0.15-0.30 mm or 0.30-0.70mm | |
| Yield Strength | 235-345 MPa or specially designed for 550 MPa | |
| Finished Products | Cover width | 1050 mm |
| Length | Adjustable | |
| Required Power | Voltage | 220V/380V/415V/440V |
| Driving Motor | 5.5 KW | |
| Cutting Motor | 2.2 KW | |
| Production Speed | 900-1200 meters per hour | |
| Coil Decoiler | Type | Un-powered or Powered |
| Capacity | 5 tons | |
| Rolling Stations | 15 sets | |
| Rolling Shaft Diameter | 72 mm | |
| Cutting Type | Post-cutting | |
| Operation System | Mitsubishi PLC, transducer and touching screen | |
| Supporting Tables | 2 sets | |
| Machine Size | Around 8.5 x 1.6 x 1.5 meters | |
| Machine Weight | Around 7.8 tons | |
Main Components Cameroun Alu-zinc Roof Sheet Corrugating Machine
| No. | Items | Quantity | |
| 1 | Coil Decoiler | 1 set | |
| 2 | Roll Former Machine | Direction Guilder | 1 set |
| Rolling System | 1 set | ||
| Post-cutting Device | 1 set | ||
| 3 | Supporting Tables for Finished Products | 2 sets | |
| 4 | Hydraulic Station for Cutting Device | 1 set | |
| 5 | PLC Control Cabinet | 1 set | |
| 6 | Tools Box with Spare Parts | 1 set | |
Applications:
With the timeless appeal of a corrugated profile, cladding is a strong and versatile roofing, walling and fencing material. It complements both contemporary and traditional architecture. It is available in long lengths and a range of thicknesses.
